Zinc Plated Steel Welded Chain

Options

Quantity

Zinc Plated Steel Welded Chain 2.5mm x 19mm – metres Code	Wire Size (mm)	Inside Length x Width (mm)	Weight/Metre (kg) (Approx)	Working Load (kg)	Finish	Pack Size (m)
19305ZC	1.6	13 x 4	0.05	15	Zinc Plated	1m Lengths
19310ZC	2.0	14 x 5	0.08	30	Zinc Plated	1m Lengths
19314ZC	2.5	14 x 6	0.11	50	Zinc Plated	1m Lengths
19318ZC	2.5	19 x 7	0.10	50	Zinc Plated	1m Lengths
19322ZC	3.0	16 x 8	0.17	85	Zinc Plated	1m Lengths
19324ZC	3.0	21 x 8	0.16	80	Zinc Plated	1m Lengths
19328ZC	3.0	26 x 8	0.15	80	Zinc Plated	1m Lengths
19332ZC	4.0	19 x 9	0.30	130	Zinc Plated	1m Lengths
19334ZC	4.0	26 x 9	0.28	120	Zinc Plated	1m Lengths
25336ZC	4.0	32 x 8	0.26	120	Zinc Plated	1m Lengths
19342ZC	5.0	21 x 11	0.50	170	Zinc Plated	1m Lengths
19344ZC	5.0	28 x 11	0.47	160	Zinc Plated	1m Lengths
25346ZC	5.0	35 x 10	0.43	160	Zinc Plated	1m Lengths
19352ZC	6.0	24 x 12	0.68	265	Zinc Plated	1m Lengths
19354ZC	6.0	33 x 13	0.62	250	Zinc Plated	1m Lengths
19358ZC	6.0	42 x 12	0.57	250	Zinc Plated	1m Lengths
19360ZC	6.5	36 x 14	0.79	290	Zinc Plated	1m Lengths
19366ZC	7.0	38 x 15	0.91	370	Zinc Plated	1m Lengths
25372ZC	8.0	32 x 16	1.31	480	Zinc Plated	1m Lengths
19375ZC	8.0	42 x 17	1.17	460	Zinc Plated	1m Lengths
25376ZC	8.0	52 x 16	1.03	455	Zinc Plated	1m Lengths
25380ZC	10.0	40 x 20	2.10	685	Zinc Plated	1m Lengths
19381ZC	10.0	53 x 18	1.84	655	Zinc Plated	1m Lengths
25382ZC	10.0	66 x 24	1.63	650	Zinc Plated	1m Lengths

* Maximum working load figures shown are for guidance only. These chains are not tested

Weight	N/A
Options	1.6mm x 13mm – metre, 2mm x 14mm – metre, 2.5mm x 14mm – metre, 2.5mm x 19mm – metre, 3mm x 16mm – metre, 3mm x 21mm – metre, 3mm x 26mm – metre, 4mm x 19mm – metre, 4mm x 26mm – metre, 4mm x 32mm – metre, 5mm x 21mm – metre, 5mm x 28mm – metre, 5mm x 35mm – metre, 6mm x 24mm – metre, 6mm x 33mm – metre, 6mm x 42mm – metre, 6.5mm x 36mm – metre, 7mm x 38mm – metre, 8mm x 32mm – metre, 8mm x 42mm – metre, 8mm x 52mm – metre, 10mm x 40mm – metre, 10mm x 53mm – metre, 10mm x 66mm – metre
Quantity	1, 2, 3, 4, 5, 6, 7, 8, 9, 10+
